Complete
Nissens part number 93500
Group: Turbo
Print PDF
TECHNICAL BULLETIN 93117+93500
The Difference
Installation Guide
Installation Video
Technical Support
Click on image or icon to view larger version
Specifications
Product size (H x W x T):
13 7/8" x 8 4/8" x 8 1/8"
Box size (L x W x H):
19 5/8" x 12" x 11 1/8"
Gross weight:
16.53 lbs
Material:
Steel/Aluminium
Outlet connection:
0
EAN:
5707286500013
Note
Move shims/plates from old actuator to new if fitted (ECU and actuator update)
NEW ITEM
Calibrate actuator - switch on ignition for 10 seconds, then switch of for 10 seconds and repeat this for totally 10 times
OE number
03F145701H
03F145701K
03F145701KX
03F145701RX
03F145701R
03F145701KV
03F145701HX
03F145701HV
